Rankin Delux TB-09 Char Broiler Pilot Tube
Specifications:
- 6" Wide, 2-1/4" To Slot X 5" X 2-5/8" X 1-1/8" X 1-1/4"
- Rankin-Delux Broiler Series Drb, Rb-8, Tb-3, Tb-8
Description
Dimensions:
- Weight: 0.1 lbs
- Length: 6.25 in
- Height: 2.25 in
- Width: 2.5 in
This Part Fits the Following Models
11 modelsStep1: Shut off gas supply and ensure equipment is fully cool.
Step2: Remove appliance access panel to reach pilot assembly area.
Step3: Disconnect existing pilot tube and mounting fittings.
Step4: Position new pilot tube in correct alignment slot.
Step5: Secure all connections tightly and check fitment.
Step6: Replace the panel, restore gas supply, inspect for leaks, then test flame ignition.
-
What maintenance is required for the Rankin Delux TB-09 Pilot Tube?
Regularly check the pilot tube for blockages, grease buildup, or corrosion. Clean gently using a soft brush or compressed air. Ensuring proper gas flow prevents uneven flame and unsafe operation. Always shut off the gas supply before servicing.
-
What are common issues with the Rankin Delux TB-09 Pilot Tube?
- Flame flickering or uneven.
- Pilot failing to ignite.
- Grease or debris buildup inside the tube.
- Improper alignment causing poor flame distribution.
