Bunn 12920.0000 Coffee Brewer Rocker Switch SPST Red Lighted On/Off 3-Terminal

SKU: 12920.0000 1-12920.0000 Brand:
Bunn
Availability:
In Stock
(0)
$14.53 Price reduced from $14.83
Save $0.30
Have a Question? +1 (866) 863-0907

Specifications:

  • Rocker Switch ] [ Fits Hole 9/16" X 1-1/8" ] [ On/Off ]
  • [ Spst ] [ Terminals 3 (1/4" Tabs) ] [ Amp/Volt
  • 15A/125V,10A/250V, 125V Lamp ] [ Color Red Light/Black]
  • Bunn-O-Matic Coffee C, Cdbc Series, Cdbc Twin, Cez, Cez
  • Twin, Cez Twin Aps, Cezf, Combo Brewer, Crt5, Crtf5, Ct,
  • Ctf, Cwaps, Cwaps-Mv, Cwt, Cwt Twin, Cwt-Aps, Cwt-Cs, Cwtf,
  • Cwtf Twin, Cwtf-Aps, Cwtf-Cs, Cwtf-Mv, Cwtf-Tc, Cwtf-Twin,
  • Cwts, Cwts-Mv, Cwtsr, Cwtsr-Mv, Single Cw, Single Cwtf,
  • Twin-Aps, Twin-Tc, Vp17, Vp17B
  • Merco Warmer
  • Nemco Hot Dog Grill
  • Prince Castle Grill Mini Clamshell: 920-D, 920-Sl.
  • Roll-A-Grill (Connelly)
  • Roundup Grill Hdc-20 (Old Style).

Description

The Bunn 12920.0000 Rocker Switch Red Lighted On/Off 3-Terminal is an electrical control system that is installed in commercial coffee brewing machines to control the power supply to the system. This single-pole single-throw rocker switch allows the operator to switch the brewer on or off along with a visible red indicator light to provide a confirmation of the power status. This is normally mounted on the control panel of commercial coffee brewers in restaurants, cafes, and institutional kitchens. The terminals are designed to aid in making the wiring system of the appliance electrically connected.

Dimensions:

  • Weight: 0.1 lbs
  • Length: 1.5 in
  • Height: 0.63 in
  • Width: 1.38 in

MERCO:

001469 001469SP

NEMCO:

47231

PRINCE CASTLE:

78-141S

ROUNDUP:

4010136

Step1: Disconnect power from the equipment before installation.

Step2: Remove the control panel cover to access the old rocker switch.

Step3: Label and disconnect the wire terminals carefully.

Step4: Push out the faulty switch from the mounting hole.

Step5: Insert the new rocker switch into the panel opening securely.

Step6: Reconnect terminals to matching positions and ensure tight connections.

Step7: Restore power and test the illuminated switch operation safely.
